Description

Features (Motor)

4 poles Hi-torque motor design.

CNC machined 6061 T6 billet aluminium heatsink can.

High purity copper windings maximizes efficiency.

High RPM ABEC5 oversized bearings.

Universal fits 1/16 1/18 brushless cars-multi-mounting system for M2.5 screws.

Precision balanced rotor, smoothness for best reliability and maximum RPM.

Stator – Super Thin (0.35mm) laminations.

Removable/replaceable.

Precision engineered for maximum energy conversion.

Features (ESC)

Compatible with sensorless brushless motors.

High anti-interference capability.

Using advanced software interface to set up or update the software.

Super smooth and accurate throttle linearity.

Fast response to throttle input.

Multiple protection features: low voltage cut-off protection, over-heat protection and throttle signal loss protection.

Specifications (Motor)

Max Amps: 18A / KV(RPM/Volt): 5800KV

Max voltage: <10.8V(2S)

IO:1.9A

Max RPM: 60000

Resistance:0.013

Max Watts: 200W

Can Diameter: 24mm/ Can Length:35mm / Shaft Diameter: 2mm

Shaft Length: 12mm

Bullet Connector: 3.5mm

Weight: 58g

Specifications (ESC)

ESC: 25A

Burst Current: 100A

Battery: 2 Cell Lipo / 4-6 Cell NiMh

BEC Output: 5V/2A

Power Supply Plugs: T Male

Motor Plugs: Female 3.5mm Bullet Connector

Resistance:0.004 ohm

Size: 25*30*14.5mm / Weight: 30g

Including

1 * 2430 5800kV brushless motor or

1 * 25A ESC or

1 * 2430 5800kV brushless motor and 1 * 25A ESC Combo
