Description

24V 20A 480W DC Switching Switch Power Supply for Power Supply Strip, CCTV High quality Switch Power Supply, Widely used in Industrial automation, LED display, etc.

With anti-jamming to ensures the long life LED lamps and reduce the LED luminous decay Smart device surge protection for Shortage, Overload, Over Voltage

There is a switch, choose the proper voltage before use The power supply fan does make a noise and the speed of the fan is load based. So the higher the load, the faster the fan runs, the louder the noise.

Connection:-

• L: FireWire
• N: zero line
• G: ground wire
• – V: load negative
• + V: load positive

Features:

• Auto on/off cooling fan
• High efficiency
• Low temperature
• LED indicator for power on
• Over Load and Short Circuit Protection
• Over Voltage Protection
• Full load burn-in test
• Great switching power supply for home appliances
• Universal AC input/full range, cooling by automatic on/off cooling fan
• A new style Switching Power Supply which can keep the voltage stability
• LED Switching Power Supply, high quality material, durable and safety in use

Kindly note:

We suggest the max use of power should be no more than 80% of the full loads, other wise, the power supply’s span life will be shortened.

Specifications:-

• Input Voltage: AC 100/264V
• Output: DC 24V 20A
• Output Power: 480W
• Frequency: 50/60Hz
• Screw Terminal Number: 9
• Fix Screw Hole Diameter: 2.5mm(0.1 inch)
• Material: Metal, Electronic Parts
• Main Color: Silver Tone
• Net Weight: 720G

Product Includes:-

1x 24V 20A 480W DC Switching Switch Power Supply for Power Supply Strip, CCTV
