Description

Relaxed soaring…aggressive climb performance…exciting, high-speed aerobatics. The Kunai offers the best of all worlds! Four-channel control accommodates all sport aerobatic maneuvers and allows the use of optional spoilerons or flaperons. The Kunais designers kept the parts count low for quick, straightforward final assembly. A great-flying model that looks awesome and is ready for fun FAST.

Key Features

• Construction: Fiberglass fuselage for high strength and low weight
• Tail Boom: Carbon fiber
• Wing: One piece, built-up, factory covered
• Canopy: Removable for battery exchange
• Controls: Ailerons (2-servos), rudder, elevator and throttle
• Brushless Motor: Factory installed 28x31mm 1400kV outrunner
• Propeller: 8×6 folding
• Spinner: Red plastic 1.25″ (32mm) diameter
• Hardware: Included

Needed to Complete

• Radio: 4-5 channel with mini receiver with front-mount plugs
• Servos: 9G
• 12″ (300mm) Servo Extensions: Two
• 3″ (75mm) Servo Extensions: Two
• ESC: 20-25A brushless compatible
• LiPo Battery: 3S, at least 850-1200mAh
• Battery Charger: LiPo compatible

What’s in the box?

• Fiberglass fuselage, main wing, tail section, hardware package, decal sheet and instruction manual

This is the Great Planes Electric Powered, Radio Controlled
Almost Ready-to-Fly 1.4M Kunai Glider.

**Additional Technical Info Will Be Added When It Becomes Available.**

FEATURES: Construction: Fiberglass fuselage for high strength and low weight
Tail Boom: Carbon fiber
Wing: One piece, built-up, factory covered
Canopy: Removable for battery exchange
Controls: Ailerons (2-servos), rudder, elevator and throttle
Brushless Motor: Factory installed 28x31mm 1400kV outrunner
Propeller: 8×6 folding
Spinner: Red plastic 1.25″ (32mm) diameter
Hardware: Included

INCLUDES: Fiberglass fuselage, main wing, tail section, hardware package,
decal sheet and instruction manual

REQUIRES: Radio: 4-5 channel with mini receiver with front-mount plugs such as
the Futaba R6106, FUTL7651
Servos: 9G
12″ (300mm) Servo Extensions: Two
3″ (75mm) Servo Extensions: Two
ESC: 20-25A brushless compatible
LiPo Battery: 3S, at least 850-1200mAh
Battery Charger: LiPo compatible such as the Duratrax 235

SPECS: Wingspan: 55″ (1395mm)
Length: 36″ (915mm)
Weight Range: 18.4-19.7 oz (520 – 560 g)
Wing Loading: 9.4 – 10.1oz/sq ft (29 – 31g/sq dm)
